Cast iron single-span bridge 110m WNW of Sherbourne House

List Entry Summary

This monument is scheduled under the Ancient Monuments and Archaeological Areas Act 1979 as amended as it appears to the Secretary of State to be of national importance. This entry is a copy, the original is held by the Department for Culture, Media and Sport.

Name: Cast iron single-span bridge 110m WNW of Sherbourne House

List entry Number: 1005883


Legacy Record - This information may be included in the List Entry Details.

The monument may lie within the boundary of more than one authority.


District: Coventry

District Type: Metropolitan Authority


National Park: Not applicable to this List entry.

Grade: Not applicable to this List entry.

This record has been generated from an "old county number" (OCN) scheduling record. As these are some of our oldest designation records they do not have all the information held electronically that our modernised records contain. Therefore, the original date of scheduling is not available electronically. The date of scheduling may be noted in our paper records, please contact us for further information.

Date first scheduled: 19-Mar-1970

Date of most recent amendment: Not applicable to this List entry.

Legacy System Information

The contents of this record have been generated from a legacy data system.

Legacy System: RSM - OCN

UID: WM 36

Asset Groupings

This list entry does not comprise part of an Asset Grouping. Asset Groupings are not part of the official record but are added later for information.

List entry Description

Summary of Monument

Legacy Record - This information may be included in the List Entry Details.

Reasons for Designation

Iron was used as one of the components of bridge construction for at least a thousand years before it was first used as the principal construction material in the Iron Bridge erected by Abraham Darby in 1779 over the Severn at Coalbrookdale. Despite its use of iron, however, the Iron Bridge simply copied existing construction techniques suited to timber, and therefore did not maximise the potential of this new material. The engineer Thomas Telford subsequently recognised that the lighter cast iron frames allowed the use of flatter angles and less substantial foundations, whilst still enabling single spans and avoiding the central piers which hindered navigation and caused instability by attracting water-scouring. The development of the single span cast iron bridge thus represented a turning point in British bridge design and engineering. All examples which retain significant original fabric are of importance. Despite having been moved the cast iron single span bridge 110m WNW of Sherbourne House survives well and retains its original features thus demonstrating its engineering design and reflecting the manufacturing process.


Legacy Record - This information may be included in the List Entry Details.


The monument includes a cast iron single-span footbridge, locally known as 'Vignoles Bridge', which crosses the River Sherbourne close to the centre of the present city of Coventry. The bridge survives as a painted metal bridge with a single elliptical arched span, geometric pierced balustrades, brick-built splayed abutments and parapets and with a tarmac covered walkway. Built in about 1835, it was designed by Charles Vignoles and cast by the Horsley Iron Works of Tipton, Staffordshire, whose name is cast onto the half arch spans on one side of the bridge. It originally spanned a branch of the Oxford canal and was moved to its present site in 1969.

Sources: PastScape 869478

Selected Sources

Legacy Record - This information may be included in the List Entry Details

National Grid Reference: SP 32699 78831


© Crown Copyright and database right 2017. All rights reserved. Ordnance Survey Licence number 100024900.
© British Crown and SeaZone Solutions Limited 2017. All rights reserved. Licence number 102006.006.
Use of this data is subject to Terms and Conditions.

The above map is for quick reference purposes only and may not be to scale. For a copy of the full scale map, please see the attached PDF - 1005883 .pdf

The PDF will be generated from our live systems and may take a few minutes to download depending on how busy our servers are. We apologise for this delay.

This copy shows the entry on 24-Feb-2017 at 03:42:12.

End of official listing
